VM-6380 3-Axis 3D Digital Vibration Meter Tester
Replace part number: VM-6380, VM6380
Application:
Fit For measuring periodic motion, to check unbalance and deflection of moving machines. Specially designed for current measurement of various mechanical vibrations. To provide data for quality control, uptime and maintenance of equipment.
Specification:
Vibration sensor: 3-axis piezoelectric accelerometer
Display: 4-digit LCD backlit
Axial vibrations: any axis of X, Y, Z or 3 axes of XYZ
Measuring range:
Speed: 0.01-400.0 mm/s 0.000-16.00 in/s true RMS
Acceleration: 0.1-400.0 m/s² 0.3-1312 ft/s² 0.0-40 g equivalent peak
Displacement: 0.001-4.000 mm 0.04-160.0 mil equivalent peak-to-peak
Frequency range for measurement: 10Hz to 10 kHz.
Accuracy: 5% of reading + 2 digits Metric/Imperial conversion
Analog output: AC output 0~2.0V peak full scale (load resistance: over 10k)
With Max. value retention and low battery indication
PC interface: RS232C or Bluetooth interface (cable and software not included)
Power supply: 2x1.5v AA batteries (UM-3).
Shutdown: Manual shutdown at any time or automatic shutdown is enabled by the user
Operating conditions:
Temperature: 0-50℃
Humidity: below 95% relative humidity
