85MM MPH GPS Speedometer Odometer 125 MPH Mileage Adjustable Overspeed Alarm for Boat Car Truck Motorcycle

85MM MPH GPS Speedometer Odometer 125 MPH Mileage Adjustable Overspeed Alarm for Boat Car Truck Motorcycle
Specification:
Cut an 85 mm (3 3/8") hole in the panel and allow a 55 mm (2 3/16") clearance behind the panel to accommodate the meter. Place the meter in the hole and screw in place.
Connection: Black wire-GND, Red-power(+), White-external button (+), Red/Yellow-Backlight, Blue-left turn, Green-Right turn, White wire-high beam
9-32V working voltage, red and yellow backlights available, indicator lights: LEFT, HIGH BEAM, RIGHT
Securely mount the GPS antenna, preferably outdoors (or inside the front windshield) so that it has a clear view of the sky to capture satellite signals. Connect the antenna cable to the socket on the back of the meter. Do not cut the cable.
Overspeed buzzer, total mileage adjustable, mileage: 0-999999 miles
Product features:
-Suitable for all vehicles and off-road vehicles
- The signal comes directly from the satellite signal receiver (GPS antenna), no other speed sensor is needed.
-The meter has the advantages of high precision, fast location confirmation and short start-up time.
-IP67 waterproof and dustproof grade
- Reverse polarity protection and anti-fog
-No paper goods operation
-Stepper motors used for the entire range of pedometers, fantastic feature with its lower power consumption, longer lifespan, higher precision, etc.
Technical data:
Mounting dimensions: 85 mm (3-3/8")
Indication range: 0-125 MPH
Working voltage: 12V/24V
Total mileage: 0-999999 miles
Travel range: 0–999.9 km
Overspeed buzzer arm: Value adjustable
Indicator lights: LEFT, HIGH BEAM, RIGHT
Backlight: red and yellow available
Operating temperature: - 40 to 85°C
Operating mode: LCD display, stepper motor
