85mm Aftermarket Eling Marine Auto GPS Speedometer Speedo Velometer 0-35MPH 0-55KM/H Odometer Backlight

85mm Aftermarket Eling Marine Auto GPS Speedometer Speedo Velometer 0-35MPH 0-55KM/H Odometer Backlight
Replace part number: B07DXTN4X1
Specification:
Cut an 85 mm (3 3/8") hole in the panel and allow a 70 mm (2 3/4") clearance behind the panel to accommodate the meter. Insert the meter into the hole and screw in place.
For the GPS antenna, you should mount it securely in a flat position, black side up, preferably outside (or inside the front windshield) so that it has a clear view of the sky to pick up satellite signals. Connect the antenna cable to the socket on the back of the meter. And do not cut the cable
It shows current speed, TRIP/COG (choose one), ODO (cannot be reset). If you need other color faceplate, pls. search for ASIN B07DY4YSJ7 and B07DXV46B5
Backlight: Red Green Blue White Yellow Orange Purple Light Green or automatic
9-32VDC (12VDC/24VDC) Working voltage, 1 year warranty, 100% waterproof and anti-img protection
Product features:
-Suitable for all cars, tractors, vans, ships, boats, yachts, etc.
- The signal comes directly from the satellite signal receiver (GPS Speed ​​Sensor)
-The meter has the advantages of high precision, fast location confirmation and short start-up time.
-IP67 waterproof and dustproof grade
-Stepper motors used for the entire range of pedometers, fantastic feature with its lower power consumption, longer lifespan, higher precision, etc.
-With curved glass (with anti-img function)
-With ultra-wide working voltage design (long-term operating voltage: 9-32V, max up to: 36V (≤ 1 min)).
Technical data:
Mounting dimensions: 85 mm (3-3/8")
Indication range: 0-35 MPH 0-55 km/h
Working voltage: 12V/24V
Travel range: 999.9 miles
ODO mileage: 99999.9 miles (not adjustable)
Backlight: Red Green Blue White Yellow Kelly Orange Purple or automatic
Operating mode: LCD display, stepper motor
Protection level: IP67
Other: waterproof and anti-fog
